YOURDIMENSIONS.CUT-READYDRAWINGS.
Stop waiting on engineers. Stop paying for drawings you could generate yourself. Pick a gate, enter your site measurements, and download a full drawing pack — orthographic views, dimension lines, cut list, and BOM — in under sixty seconds.
Every Drawing You Wait For Is Money Left On The Table.
You can weld it. You can measure it. But you still need someone else to draw it before you can start. A three-day drawing delay on a $4,000 gate job costs you $800 in idle time — and that's before counting the quotes you never sent because turnaround was too slow.
The Waiting Game
You take site measurements Monday. Email them to your draftsperson. Wait two days. Get drawings Thursday. Find a wrong dimension. Email back. Wait again. The material sits. The client chases you.
The Mistake Tax
A transposed number. A missing dimension. You cut the steel, tack it up, and the frame doesn't fit the opening. That's your time, your material, and your margin — gone. Hand-drawn numbers are the most expensive mistakes in the shop.
The Quotes You Never Sent
A job lands in your inbox. You know you can do it. But your draftsperson is backed up and turnaround is three days — and the client wants drawings by tomorrow. You pass. That's not a delay. That's a job someone else won.
Built For
- Independent welders and metal fabricators
- Small fab shops quoting residential and commercial gates
- Anyone who takes site measurements and needs drawings fast
Not For
- Structural engineers needing PE-stamped drawings
- Architects producing full construction documentation
- Anyone who needs certified load calculations
Dimensions In. Drawings Out.
Browse the sheets and spin the 3D model. This is real output from the engine made in under 45 seconds.
Tap to expand
Loading 3D view…
Sheet 1 of 7 — Front
A Complete Drawing Pack.
Every sheet, every dimension, every cut — generated from your measurements in under sixty seconds.
Orthographic Views
Front, top, and side projections of every component
3D Rendering
Interactive 3D model you can orbit, zoom, and inspect from any angle
Dimension Lines
Every measurement your workshop needs to cut and weld
Cut List
Every piece, every length, ready for the saw
Bill of Materials
Steel weights and quantities for ordering
Title Block
Job name, date, revision number, drawing scale
Do The Numbers.
| Without CADdition | With CADdition | |
|---|---|---|
| Drawing turnaround | 2–5 days | 60 seconds |
| Cost per drawing pack | $150–$400 | Free |
| Mistakes from manual dims | 1 in 5 jobs | Computed from model |
| Jobs you can quote per week | Limited by drafting | Unlimited |
What Fabricators Say
Real messages. Unedited.
Measure The Opening. Download The Drawings.
See exactly what happens at each step — from browsing the catalogue to holding a finished drawing pack.
Pick a Product
Browse the catalogue and pick the model that fits your job.
Timber-look privacy gate with full batten infill.
Horizontal slat infill on a rolling track frame.
Twin-leaf battened gate for wide driveways.
Enter Your Dimensions
Enter your site measurements. The model recalculates everything — frame sizes, hinge positions, clearances.
40 x 40 SHS, 3mm gauge
65 x 65 SHS, footplates on
150 x 150 x 8mm, 4-bolt pattern
70 x 19mm, 10mm spacing
Left panel, 600mm wide
Heavy-duty hinges, padbolt latch
All dimensions in millimetres
Review Your Drawings
Four orthographic views with full dimension lines — computed from the model, not hand-drawn.
Tap to expand
Loading 3D view…
Sheet 1 of 3 — Front
Download & Send for Approval
Print the A4 drawing pack or send it straight to your customer for sign-off. That's it — you're ready to fabricate.
PDF Drawing Pack
Print-ready A4 sheets with title block and dimensions
Customer Approval
Email the PDF to your client for sign-off before fabrication
STEP File
Export for CAD software if needed
Yeah, But…
The questions every fabricator has... and the straight answers.
Every drawing is computed from a full 3D solid model using CadQuery — the same OCCT geometry kernel used in FreeCAD and professional CAD tools. Dimensions are accurate to sub-millimetre precision. Four orthographic views are projected from the model, not hand-drawn or stretched. The output is a proper engineering drawing pack — the same quality you'd get from a draftsperson, generated in seconds.
That's exactly why this exists. Enter your actual site dimensions — opening width, post height, tube sizes — and the engine rebuilds everything from scratch: the 3D model, dimension lines, cut list, and BOM. Nothing is stretched or scaled. Every measurement is recomputed for your specific job.
You don't need to. There's no software to install, no files to manage, no CAD commands to learn. You pick a product, type in your measurements, and hit generate. If you can measure an opening and fill in a form, you can use CADdition. The whole thing takes sixty seconds from start to finish.
Change the number, hit generate, and you've got a new drawing pack in sixty seconds. No emailing a drafter. No waiting two days. No revision fee. The old way punishes you for changes. This way, changes cost you nothing.
There isn't one. No credit card. No account. No trial that expires. You generate a drawing pack, download the PDF, and it's yours — print it, email it, pin it to the workshop wall. The output is full-quality, production-ready. We're building the tool we wish existed when we needed fabrication drawings fast.
